PDS108KCS
Brochures
| Busbar voltage (VDC) | 350 |
| Ratio | 7.1 |
| Rated power (kW) | 2x60 |
| Peak power (kW) | 2x150@400V |
| Wheel rated speed (rpm) | 541 |
| Wheel peak speed (rpm) | 1702 |
| Wheel rated torque (N·m) | 2x1033 |
| Wheel peak torque (N·m) | 2x2273 |
| Drive form | Central distributed drive |
| Assembly power density (kW/kg) | 3 |
| Assembly maximum efficiency | 92% |
| Assembly weight (kg) | 100 |
| Assembly dimensions (mm) | 533x480x332 |
